GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices
GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices
GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices
Contact Now

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices

Minimum Order Quantity : 32PCS Price : Please contact us for details.
Packaging Details : CARTON WITH FOAM BOX AND ANIT-CORRISON PROTECT. Delivery Time : 14 DAYS
Payment Terms : Western Union, MoneyGram, T/T Supply Ability : 1000 PCS / MONTH
Place of Origin: GUANGZHOU, CHINA Brand Name: GDHY
Certification: SGS,ISO Model Number: C41501205KBA1301-01

Detail Information
BRAND: GDHY SUPPLIER TYPE: ORIGINAL MANUFACTURER
MODEL NUMBER: C41501205KBA1301-01 CAPACITANCE: 2.0μF
RATED VOLTAGE: 500V TOLERANCE: ±10%
DIMENSION: 80*80*36.5 OPERATION TEMP: -40℃～85℃
TERMINAL: COPPER CERTIFICATION: SGS, ISO
Highlight:

Water Cooled Capacitor 2.0UF 500V

,

Water Cooled Capacitor for Resonant Tank

Product Description

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 0GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices





Technical Parameter



Model code C41501205KBA1301-01
Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range 2.0μF
Rated capacitance 100kVar-1500kVar
Rated Voltage 400VAC-1100VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Specification download: C41-BA1.pdf



Application



● Suitable for high power and high frequency resonant deviceds.

● Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.



Feature



● Conduction water-cooled, self-healing

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High stability, high voltage, high frequency and high dV/dt

● Can bear large current, excellent heat dissipation



Product Picture

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 1GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 2



Product shape



GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 3



Production

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 4



Workshop& Equipment

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 5



Packing method

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 6

Certificate

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 7

Exhibition

GDHY Water Cooled Capacitor C41-BA1 2uF 500VAC 300kVar (Alcon FP-7-300) for High Power And High Frequency Resonant Devices 8
