GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine

Contact Now

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine

Minimum Order Quantity :	32PCS	Price :	Please contact us for details.
Packaging Details :	plastic bag and carton	Delivery Time :	14 DAYS
Payment Terms :	Western Union, MoneyGram, T/T	Supply Ability :	1000 PCS

Place of Origin:	GUANGZHOU, CHINA	Brand Name:	GDHY
Certification:	SGS,ISO	Model Number:	C41-BB2-1.5UF/500V.AC

Detail Information
Place Of Origin:	Guangzhou, China	Supplier Type:	Original Manufacturer
Classification:	Polypropylene Film Capacitor	Model Number:	C41501155KBB2301-01
Material:	Metallized Polypropylene Film	Operating Temperature Range:	-40℃～+85℃
Capacitance:	1.5UF
Highlight:	500VAC Water Cooled Capacitor , 1UF Water Cooled Capacitor

Product Description

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Capacitance range	0.1uF～85uF
Operating Temperature Range	-40°℃~85°℃
Rated Capacitance	100kVar-1500 kVar
Rated Voltage	400VAC-1100VAC
Capacity Tolerance	士5%±10%
Dissipation factor	tg6≤5×10-4 at 25℃土5℃,1kHz
Insulation resistance	R·C≥3000s, at 100VDC,25℃土5℃,60s

Specification download: C41-BB2.pdf

Application

Widely used in high power and high frequency resonant devices

Features

Conduction water-cooled
Polypropylene dielectric
Low dissipation factor(tg6),low ESL and low ESR
High voltage, high frequency and high dv/dt
High current resistance, excellent heat dissipation

Product picture

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine 1

Product shape

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine 3

Production

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine 4

Workshop& Equipment

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine 5

Packing method

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine 6

Certificate

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine 7

Exhibition

GDHY Water Cooled Capacitor C41-BB2 1.5uF 500V 300KVar (Alcon FP-7-300) for Induction Melting Machine 8
