GDHY Water Cooled Capacitor C41-TC2 0.66uF 600V 150kVar (Alcon FP-4-150/Celem CSM150) for Induction Heating Machines
Contact Person : Roger Law
Phone Number : +86 189 8890 2989
WhatsApp : +8618988902989
| Minimum Order Quantity : | 32PCS | Price : | PLEASE CONTACT US FOR DETAILS |
|---|---|---|---|
| Packaging Details : | CARTON WITH FOAM BOX AND ANIT-CORRISON PROTECT. | Delivery Time : | 14 DAYS |
| Payment Terms : | Western Union, MoneyGram, T/T | Supply Ability : | 1000 PCS / MONTH |
| Place of Origin: | GUANGZHOU, CHINA | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | C41701106KBB3501-01 |
|
Detail Information |
|||
| BRAND: | GDHY | MODEL NUMBER: | C41701106KBB3501-01 |
|---|---|---|---|
| SUPPLIER TYPE: | ORIGINAL MANUFACTURER | EXPERIENCE: | OVER 22 YEARS |
| DIELECTRIC: | POLYPROPYLENE | ELECTRODES: | COPPER FOIL |
| MAX. OPERATING TEMPERATURE: | 85℃ | APACITANCE: | 10μF |
| TOLERANCE: | ±10% | RATED VOLTAGE: | 700V |
| DIMENSION: | 100*100*54MM | LIFE EXPECTANCY: | 100000h At UN And 70℃,30000h At Urms |
| APPLICATION: | WIDELY USED IN HIGH FREQUENCY RESONANT CIRCUITS | INSTALLATION: | THROUGH HOLE |
| CERTIFICATION: | SGS, ISO | ||
| Highlight: | 300KVAR Water Cooling Capacitor,0.1UF Water Cooling Capacitor,GDHY Water Cooled Capacitor |
||
Product Description
GDHY WATER COOLED CAPACITOR C41-BB3 10UF 700V 500kVar (Alcon FP-36-500) INDUCTION HEATING LOW DF
| Reference Standards | GB/T 3984-2004 IEC 60110.1 |
| Capacity Range | 0.1μF~85μF |
| Power Range | 100kVar-1500kVar |
| Rated Voltage | 700VAC |
| Capacity Tolerance | ±10% |
| Operating Temperature Range | -40℃～85℃ |
| Test Voltage between Terminals | 1.5UNAC 10s |
| 2~3.5UNDC 10s at 25℃±5℃ | |
| Dissipation Factor | tgδ≤5×10-4 at 25℃±5℃,1kHz |
| Insulation Resistance | R•C≥3000s,at 100VDC,25℃±5℃,60s |
| Life Expectancy | 100000h at UN and 70℃,30000h at Urms |
Application
Can be used in applications include: Resonant power supplies, induction heating, RF Amplifiers, welding equipment, heat treatment, medical imaging, wireless power transfer, electric vehicle charging, IPT, high frequency inverters,etc.
Feature
● Conduction water-cooled
● Polypropylene dielectric
● Low dissipation factor(tgδ), ESL and ESR
● Operating temperature ranges from -40℃～85℃
● High voltage, high frequency and high dV/dt; high current resistance
● Excellent heat dissipation
● Stable performance, quality approved
Product Picture
Product shape
Production
Workshop& Equipment
Packing method
Certificate
Exhibition
