ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor
ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor
Contact Now

ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor

Minimum Order Quantity : 20 PCS Price : USD 120-140/PCS
Packaging Details : CARTON WITH FOAM BOX AND ANIT-CORROSION PROTECT. Delivery Time : 14 DAYS
Payment Terms : Western Union, T/T, MoneyGram Supply Ability : 1000PCS/MONTH
Place of Origin: GUANGZHOU, CHINA Brand Name: GDHY
Certification: CQC, KC, VDE, UL, SGS ETC Model Number: C41701664KBC5301-01

Detail Information
BRAND: GDHY PLACE OF ORIGIN: GUANGZHOU, CHINA
SUPPLIER TYPE: ORIGINAL MANUFACTURER MODEL NUMBER: C41701664KBC5301-01
CHARACTERISTICS: WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION. CORE: IMPORTED COPPER FOIL
TERMINAL: COPPER CERTIFICATION: SGS, ISO
OPERATION TEMP: -40℃～85℃ CAPACITANCE: 0.66UF
TOLERANCE: ±10% RATED POWER: 300KVAR
RATED VOLTAGE: 700VAC LIFE EXPECTANCY: 100000h At UN And 70℃,30000h At Urms
DIMENSION: 60*60*30.2 ADVANTAGE: KEEP LOW DF AND LONG LIFE EXPECTANCY
PRINTING: LASER MARKING APPLICATION: NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES:
EXPERIENCE: OVER 22 YEARS INSTALLATION: THROUGH HOLE
High Light:

CSP305B High Power Capacitor

,

CELEM CSP305B

,

ALCON FP-8-300-4H

Product Description

ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor 0C41-BC5 0.66UF/700VRMS/300KVAR (ALCON FP-8-300-4H/CELEM CSP305B) HIGH POWER CAPACITORS CAPACITORS SUPPLIERS WATER-COOL





Technical Parameter

Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range 0.66μF
Power Range 300 kVar
Rated Voltage 700VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Specification download: C41-BC5.pdf





Application



*Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.



Feature



● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt

● Can bear large current, excellent heat dissipation



Product Picture

ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor 1



Product Shape



C41-BC5 0.33UF/700Vrms/300Kvar for induction heating (FP-8-300-4H/Celem CSP305B)High Frequency Capacitor 1



Production

ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor 3



Workshop&Equipment

ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor 4



Packing method

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

Certificate

ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor 6

Exhibition

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7

ALCON FP-8-300-4H CELEM CSP305B High Power Capacitor 8
