GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor
GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor
Contact Now

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor

Minimum Order Quantity : 20 PCS Price : 107 USD /PCS
Packaging Details : CARTON PACKING WITH FOAM BOX AND ANTI-CORRSION PROTECT. Delivery Time : 14 DAYS
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 1000 PCS/ MONTH
Place of Origin: GUANGZHOU, CHINA. Brand Name: GDHY
Certification: ISO,SGS Model Number: C41102503KTC2151-01

Detail Information
BRAND NAME: GDHY MODEL NUMBER: C41102503KTC2151-01
CORE: IMPORTED COPPER FOIL MATERIAL: BRONZE
INSTALLATION: THROUGH HOLE CAPACITANCE VALUE: 0.05UF
RATED POWER: 150KVAR RATED VOLTAGE: 1000VAC
OPERATION TEMPERATURE: -40℃～85℃ CERTIFICATION: ISO,SGS
CAPACITY TOLERANCE: ±10% DIMENSION: 68*30*30.2MM
LIFE EXPECTANCY: 100000h At UN And 70℃,30000h At Urms LEAD EKECTRODE: COPPER
ADVANTAGE: KEEP LOW DF AND LONG LIFE EXPECTANCY SHAPE: SQAURE
PRINTING METHOD: LASER MARKING QUALITY CERTIFICATE: ISO 9001
COMPANY HISTORY: SINCE 1998 FREQUENCY: 478-700KHZ
CURRENT: 200A APPLICATION: Induction Heating, Heat Treatment, Plasma Applications, Resonant Circuits, Medical Imaging, Wireless Power Transfer, EV (electric Vehicle) Charging, IPT, High Frequency Inverters,etc.
High Light:

1000V Induction Heating Capacitor

,

FP-4-150-SM/SP

,

GDHY Induction Heating Capacitor

Product Description

C41-TC2 0.05UF/1000V/150KVAR ALCON FP-4-150-SM/SP CELEM CSM150 INDUCTION HEATER FURNACE CAPACITOR





Technical Parameter



Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range 0.1μF
Power Range 300 kVar
Rated Voltage 1000VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Specification download: C41-TC2.pdf





Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.





Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation



Product Picture

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor 0





Product Shape

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor 1

Production Line

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor 2





Workshop&Equipment

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor 3

Packing Method

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor 4



Certification

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor 5



Exhibition

GDHY FP-4-150-SM/SP 1000V Induction Heating Capacitor 6



Tag:

FP-4-150-SM/SP

150KVAR Conduction Cooled Capacitor

0.17μF Conduction Cooled Capacitor
