GDHY 1.2UF 600V Resembling CELEM CSM150 Induction Heater Capacitor

Minimum Order Quantity :	20 PCS	Price :	Please contact us for details.
Packaging Details :	CARTON PACKING WITH FOAM BOX AND ANTI-CORRSION PROTECT.	Delivery Time :	14 DAYS
Payment Terms :	T/T, Western Union,	Supply Ability :	1000 PCS/ MONTH

Place of Origin:	GUANGZHOU, CHINA.	Brand Name:	GDHY
Certification:	SGS,ISO	Model Number:	C41601125KTC2201-01

Detail Information
BRAND NAME:	GDHY	MODEL NUMBER:	C41601125KTC2201-01
CORE:	IMPORTED COPPER FOIL	MATERIAL:	COPPER
INSTALLATION:	THROUGH HOLE	CAPACITANCE VALUE:	1.2UF
RATED POWER:	200KVAR	RATED VOLTAGE:	600V
RATED VOLTAGE:	600V	OPERATION TEMPERATURE:	-40℃～85℃
CERTIFICATION:	SGS, ISO	CAPACITY TOLERANCE:	±10%
DIMENSION:	683030.2MM	LIFE EXPECTANCY:	100000h At UN And 70℃,30000h At Urms
LEAD EKECTRODE:	COPPER	ADVANTAGE:	KEEP LOW DF AND LONG LIFE EXPECTANCY
SHAPE:	SQAURE	PRINTING METHOD:	LASER MARKING
PRINTING METHOD:	LASER MARKING	QUALITY CERTIFICATE:	ISO 9001
QUALITY CERTIFICATE:	ISO 9001	APPLICATION FIELD:	NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING
APPLICATION FIELD:	NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING	COMPANY HISTORY:	SINCE 1998
COMPANY HISTORY:	SINCE 1998
Highlight:	600V CELEM CSM150 Capacitor , CELEM CSM150 power capacitor , 600V Induction Heater Capacitor

Product Description

GDHY 1.2UF 600V Resembling CELEM CSM150 Induction Heater Capacitor GDHY C41-TC2 1.2UF/600V/200KVAR RESEMBLING ALCON FP-4-150-SM/SP CELEM CSM150 LARGE INDUCTION HEATER CAPACITOR POWER INDUCTION

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Operating Temperature Range	-40℃～85℃
Capacity Range	1.2μF
Power Range	200 kVar
Rated Voltage	600VAC
Capacity Tolerance	±10%
Test Voltage between Terminals	1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor	tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance	R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy	100000h at UN and 70℃,30000h at Urms

Specification download: C41-TC2.pdf

Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation
