ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor
ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor
Contact Now

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor

Minimum Order Quantity : 20 PCS Price : 107 USD /PCS
Packaging Details : CARTON PACKING WITH FOAM BOX AND ANTI-CORRSION PROTECT. Delivery Time : 14 DAYS
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 1000 PCS/ MONTH
Place of Origin: GUANGZHOU, CHINA. Brand Name: GDHY
Certification: CQC, KC, VDE, UL, SGS ETC Model Number: C41501135KTC2151-01

Detail Information
BRAND NAME: GDHY MODEL NUMBER: C41501135KTC2151-01
CORE: IMPORTED COPPER FOIL MATERIAL: COPPER
INSTALLATION: THROUGH HOLE CAPACITANCE VALUE: 1.3UF
RATED POWER: 150KVAR RATED VOLTAGE: 500V
OPERATION TEMPERATURE: -40℃～85℃ CERTIFICATION: SGS, ISO
CAPACITY TOLERANCE: ±10% DIMENSION: 68*30*30.2MM
LIFE EXPECTANCY: 100000h At UN And 70℃,30000h At Urms LEAD EKECTRODE: COPPER
ADVANTAGE: KEEP LOW DF AND LONG LIFE EXPECTANCY SHAPE: SQAURE
PRINTING METHOD: LASER MARKING QUALITY CERTIFICATE: ISO 9001
APPLICATION FIELD: NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING COMPANY HISTORY: SINCE 1998
High Light:

CSM150 150 Kvar Capacitor

,

FP-4-150-SM/SP CELEM CSM150

,

Polypropylene GDHY capacitor

Product Description

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 0C41-TC2 1.3UF/500V/150KVAR ALCON FP-4-150-SM/SP CELEM CSM150 POWER CAPACITOR SUPPLIERS POWER CAPACITORS





Technical Parameter



Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range

1.3μF
Power Range 150 kVar
Rated Voltage 500VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.





Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation



Product Picture

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 1



Specification download: C41-TC2.pdf



Product Shape

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 2

Production Line

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 3





Workshop&Equipment

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 4

Packing Method

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 5



Certification

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 6



Exhibition

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 7

ALCON FP-4-150-SM/SP CELEM CSM150 150 Kvar Capacitor 8
