ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor
ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor
Contact Now

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor

Minimum Order Quantity : 20 PCS Price : 107 USD/ PCS
Packaging Details : CARTON WITH FOAM BOX AND ANTI-CORRSION PROTECTION Delivery Time : 14 DAYS
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 1000 PCS /MONTH
Place of Origin: GUANGZHOU, CHINA Brand Name: GDHY
Certification: CQC, KC, VDE, UL, SGS ETC Model Number: C41701664KTC2201-01

Detail Information
BRAND NAME: GDHY CHARACTERISTICS: WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION.
CORE: IMPORTED COPPER FOIL CAPACITANCE VALUE: 0.66μF
RATED POWER: 200KVAR RATED VOLTAGE: 700V
OPERATION TEMPERATURE: -40℃～85℃ CAPACITY TOLERANCE: ±10%
LIFE EXPECTANCY: 100000h At UN And 70℃,30000h At Urms DIMENSION: 68*30*30.2 MM
PRINTING METHOD: LASER MARKING QUALITY CERTIFICATE: ISO 9001
MATERIAL: BRONZE APPLICATION FIELD: NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING
COMPANY HISTORY: SINCE 1998 EXPERIENCE: OVER 22 YEARS
INSTALLATION: THROUGH HOLE ADVANTAGE: KEEP LOW DF AND LONG LIFE EXPECTANCY
High Light:

CELEM CSM 150

,

ALCON FP-4-150-SM/SP

,

CSM 150 Resonant Film Capacitor

Product Description

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 0C41-TC2 0.66UF/700V/200KVAR ALCON FP-4-150-SM/SP CELEM CSM 150 FILM CAPACTIOR RESONANT CONDUCTION COOLED



Technical Parameter



Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range 0.66μF
Rated Power 200kVar
Rated Voltage 700VAC
Capacity Tolerance  ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Specification download: C41-TC2.pdf





Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation



ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 1



Product Shape

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 2



Workshop&Equipment

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 3

Prodcution

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 4



Packing

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 5



Exhibition

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 6

Certification

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 7





Comparison

ALCON FP-4-150-SM/SP CELEM CSM 150 Resonant Film Capacitor 8
