Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor

Contact Now

Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor

Minimum Order Quantity :	20pcs	Price :	USD110
Delivery Time :	14days	Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	1000PCS/MONTH

Place of Origin:	China	Brand Name:	GDHY
Certification:	ISO,SGS	Model Number:	C41102104KBX2151-01

Detail Information
Capacity:	0.1uF	Voltage:	1000VAC
Size:	68mm30mm30.2mm	Power:	150KVAR
Frequency:	238-423KHZ	Model:	C41102104KBX2151-01
Brand:	GDHY	Terminal:	Copper
Capacity Tolerance:	±5% ~ ±10%	Material:	Polypropylnen Film&Copper
Series:	Conduction Cooled Capacitor	Place Of Original:	China
Max Irm:	250A	Application:	Induction Heating, Heat Treatment, Plasma Applications, Resonant Circuits, Medical Imaging, Wireless Power Transfer, EV (electric Vehicle) Charging, IPT, High Frequency Inverters,etc.
High Light:	Celem CSP150 Capacitor , 150KVar Polypropylene Capacitor , 0.1UF 1000V Polypropylene Capacitor

Product Description

C41-BC2 0.1UF 1000V 150KVar Alcon FP-4-150-SM/SP and Celem CSP150 Polypropylene Conduction-cooled Capacitor

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Operating Temperature Range	-40℃～85℃
Capacity Range	0.25μF～2.4μF
Power Range	150kVar-200 kVar
Rated Voltage	400-1000VAC
Capacity Tolerance	±5% ~ ±10%
Test Voltage between Terminals	1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor	tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance	R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy	100000h at UN and 70℃,30000h at Urms

Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt

● Can bear large current, excellent heat dissipation

Product Picture

Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor 0

Product Shape

Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor 1

Workshop&Equipment

Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor 2

Exhibition

Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor 3

Certification

Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor 4

Packing Method

Celem CSP150 0.1UF 1000V 150KVar Polypropylene Capacitor 5
