300kVar 400VAC 4000nF Resonant Water Cooled Capacitor

Contact Now

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor

Minimum Order Quantity :	20	Price :	212 USD/ PCS
Packaging Details :	CARTON WITH FOAM BOX	Delivery Time :	14 DAYS
Payment Terms :	L/C, T/T, Western Union, MoneyGram	Supply Ability :	1000PCS/MONTH

Place of Origin:	GUANGZHOU, CHINA	Brand Name:	GDHY
Certification:	CQC, KC, VDE, UL, SGS ETC	Model Number:	C41401405JBA1301-01

Detail Information
BRAND NAME:	GDHY	MODEL NUMBER:	C41401405JBA1301-01
CHARACTERISTICS:	WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION.	MATERIAL:	IMPORTED COPPER FOIL
CERTIFICATION:	SGS, ISO	CAPACITANCE VALUE:	4μF
RATED POWER:	300KVAR	RATED VOLTAGE:	400VAC
OPERATION TEMPERATURE:	-40℃～85℃	CAPACITY TOLERANCE:	±10%
LIFE EXPECTANCY:	100000h At UN And 70℃,30000h At Urms	ADVANTAGE:	KEEP LOW DF AND LONG LIFE EXPECTANCY
LEAD ELECTRODE:	COPPER	PRINTING METHOD:	LASER MARKING
QUALITY CERTIFICATE:	ISO 9001	APPLICATION FIELD::	NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING
COMPANY HISTORY:	SINCE 1998	PRODUCTION MODE:	AUTOMATIC
EXPERIENCE:	OVER 22 YEARS	DIMENSION:	808036.5MM
High Light:	Resonant Water Cooled Capacitor , 4000nF Water Cooled Capacitor , 300kVar Power Film Capacitor

Product Description

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 0 C41-BA1 (ALCONFP-7-300/ CELEM CSP150) POWER FILM CAPACITOR RESONANT WATER COOLED CAPACITOR

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Operating Temperature Range	-40℃～85℃
Capacity Range	4μF
Capacity Range	300kVar
Rated Voltage	400VAC
Capacity Tolerance	±10%
Test Voltage between Terminals	1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor	tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance	R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy	100000h at UN and 70℃,30000h at Urms

Download specification: C41-BA1.pdf

Application

Induction Heating, Electric Cars, Medical Imaging, EV Wireless Chargers, Resonant Circuits.

Features

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation

Product Picture

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 1

Product Shape

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 2

Workshop&Equipment

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 3

Certification

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 4

Exhibition

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 5

Packing Method

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 6

300kVar 400VAC 4000nF Resonant Water Cooled Capacitor 7
