300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor
300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor
300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor
Contact Now

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor

Minimum Order Quantity : 20 PCS Price : 212 USD /PCS
Packaging Details : CARTON WITH FOAM BOX AND ANTI-CORROSION PROTECT Delivery Time : 14 DAYS
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 1000 PCS /MONTH
Place of Origin: GUANGZHOU, CHINA Brand Name: GDHY
Certification: CQC, KC, VDE, UL, SGS ETC Model Number: C41102664KBA1301-01

Detail Information
BRAND: GDHY PLACE OF ORIGIN: GUANGZHOU, CHINA
SUPPLIER TYPE: ORIGINAL MANUFACTURER MODEL NUMBER: C41102664KBA1301-01
CHARACTERISTICS: WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION. CORE: IMPORTED COPPER FOIL
OPERATION TEMP: -40℃～85℃ CERTIFICATION: SGS, ISO
TERMINAL: COPPER CAPACITANCE: 0.66μF
TOLERANCE: ±10% RATED POWER: 300KVAR
RATED VOLTAGE: 1000VAC DIMENSION: 80*80*36.5
LIFE EXPECTANCY: 100000h At UN And 70℃,30000h At Urms ADVANTAGE: KEEP LOW DF AND LONG LIFE EXPECTANCY
PRINTING: LASER MARKING APPLICATION: NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES
QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING INSTALLATION: THROUGH HOLE
High Light:

FP-7-300

,

1kV Water Cooling Capacitor

,

0.66UF Water Cooling Capacitor

Product Description

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 0C41-BA1 0.66UF/1000V/300KVAR (ALCONFP-7-300/ CELEM CSP150)WATER-COOLING CAPACITOR INDUCTION COIL WATER HEATER CAPACITOR





Technical Parameter



Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃～85℃
Capacity Range 0.66μF
Capacity Range 300kVar
Rated Voltage 1000VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms


Download specification:C41-BA1.pdf





Application

Induction Heating, Electric Cars, Medical Imaging, EV Wireless Chargers, Resonant Circuits.





Features



● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation



Product Picture

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 1



Product Shape

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 2



Production Line

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 3



Workshop&Equipment

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 4



Packing Method

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 5



Certificates

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 6



Exhibition

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 7

300KVAR FP-7-300 0.66UF 1kV Water Cooling Capacitor 8
