224nF Metallized Film Capacitors 630VDC 15MM Pitch
Contact Person : Roger Law
Phone Number : +86 189 8890 2989
WhatsApp : +8618988902989
| Minimum Order Quantity : | 100KPCS | Price : | PLEASE CONTACT US FOR MORE DETAILS |
|---|---|---|---|
| Packaging Details : | PLASTIC BAG | Delivery Time : | 15 WORKING DAYS |
| Payment Terms : | Western Union, T/T, MoneyGram | Supply Ability : | 1KK PCS/MONTH |
| Place of Origin: | GUANGZHOU, CHINA | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | CBB22 824J400V P20 |
|
Detail Information |
|||
| DIELECTRIC: | METALLIZED POLYPROPYLENE FILM | CAPACITANCE: | 0.82UF/824 |
|---|---|---|---|
| RATED VOLTAGE: | 400V | DIMENSION: | 23*8.5*15mm |
| PITCH: | 20MM | ENCAPSULATION: | FLAME RETARDANT EPOXY RESIN POWDER |
| Highlight: | 0.82UF 400V Polypropylene Film Capacitor,400V CBB22 Polypropylene Film Capacitor,LED Lighting Circuit Board Film Capacitor |
||
Product Description
GDHY 0.82UF 400V CBB22 METALLIZED POLYPROPYLENE FILM CAPACITOR P20 AUDIO INDUSTRY LIGHTING POWER
| Model number | B8240400-D-20-1R |
| Reference Standards | GB/T 10190(IEC 60384-16) |
| Climate Category | 40/085/21 |
| Operating Temperature Range | from -40℃ to +85℃ |
| Capacity Range | 0.82μF |
| Rated Voltage | 400V |
| Capacity Tolerance | ±5%(J);±10%(K) |
| Withstand voltage | Vt-t:1.6UN 5S (at20 ±5%) |
| Dissipation Factor | tgδ≤0.0010 (20℃, 1KHz) |
| Maximum Pulse Rise Time (dv/dt) | 180(V/μS) |
| Insulation Resistance | RCN≥30000S (at20℃ 100VDC 1Min) |
Application
Widely used in High frequency, DC, AC, Pulse Circuits, and the S-correction circuits of the display device.
Suitable for Lighting industry, Audio industry, Automation industry, Power industry, Household appliance, Telecommunication industry.
Feature
● Non-inductive winding structure
● Good stability and reliability, high insulation resistance
● Good self-healing
● Resistance to high voltage, small tgδ, low temperature rise
Product Picture
Product Shape
Production
Workshop&Equipment
Packing method
Certificate
Exhibition
