100000h Water Cooled Capacitor 0.33uF For EMI UPS
Contact Person : Roger Law
Phone Number : +86 189 8890 2989
WhatsApp : +8618988902989
| Minimum Order Quantity : | 20pcs | Price : | USD30/PC |
|---|---|---|---|
| Delivery Time : | 14days | Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 1000PCS/ MONTH |
| Place of Origin: | China | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | C41701254KBB2301-01 |
|
Detail Information |
|||
| Capacity: | 0.25uF | Voltage: | 700VAC |
|---|---|---|---|
| Size: | 80mm*80mm*36mm | Power: | 300KVAR |
| Frequency: | 390-530KHZ | Model: | C41701254KBB2301-01 |
| Capacity Tolerance: | ±5% ~ ±10% | Material: | Polypropylnen Film&Copper |
| Series: | Water Cooled Capacitor | Place Of Original: | China |
| Max Irm: | 500A | Application: | Induction Heating, Heat Treatment, Plasma Applications, Resonant Circuits, Medical Imaging, Wireless Power Transfer, EV (electric Vehicle) Charging, IPT, High Frequency Inverters,etc. |
| Highlight: | 0.25uF Induction Melting Capacitor,300KVar Water Cooled Capacitor,700VAC Water Cooled Capacitor |
||
Product Description
| Reference Standards | GB/T 3984-2004 IEC 60110.1 |
| Operating Temperature Range | -40℃～85℃ |
| Capacity Range | 0.33μF~4μF |
| Power Range | 300~400kVar |
| Rated Voltage | 400-1100VAC |
| Capacity Tolerance | ±5% ~ ±10% |
| Test Voltage between Terminals | 1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃ |
| Dissipation Factor | tgδ≤5×10-4 at 25℃±5℃,1kHz |
| Insulation Resistance | R•C≥3000s,at 100VDC,25℃±5℃,60s |
| Life Expectancy | 100000h at UN and 70℃,30000h at Urms |
Application
Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.
Features
● Conduction water-cooled
● Polypropylene dielectric
● Low dissipation factor(tgδ), low ESL, low ESR
● High voltage, high frequency and high dV/dt,
● Can bear large current, excellent heat dissipation
Product Picture
Product Shape
Workshop&Equipment
Exhibition
Certification
Packing Method
