Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor

Contact Now

Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor

Minimum Order Quantity :	20pcs	Price :	USD500/PC
Delivery Time :	14days	Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	1000PCS/MONTH

Place of Origin:	China	Brand Name:	GDHY
Model Number:	C41701684KTD1501-01

Detail Information
Capacity:	0.68uF	Voltage:	700VAC
Size:	120mm80mm30.5mm	Power:	500KVAR
Frequency:	239-467KHZ	Model:	C41701684KTD1501-01
Brand:	GDHY	Terminal:	Copper
Capacity Tolerance:	±5% ~ ±10%	Material:	Polypropylnen Film&Copper
Series:	Induction Heating Capacitor	Place Of Original:	China
Max Irms:	1000A	Application:	Induction Heating, Heat Treatment, Plasma Applications, Resonant Circuits, Medical Imaging, Wireless Power Transfer, EV (electric Vehicle) Charging, IPT, High Frequency Inverters,etc.
High Light:	0.68uF Induction Heating Capacitor , CSP505 Induction Heating Capacitor , Alcon FP-11R-500

Product Description

C41-TD1 0.68UF 700V same as Alcon FP-11R-500 and Celem CSP505 for induction forging machine Induction Heating Capacitor

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Operating Temperature Range	-40℃～85℃
Capacity Range	0.2μF～1μF
Capacity Range	400kVar-500 kVar
Rated Voltage	400-1100VAC
Capacity Tolerance	±5% ~ ±10%
Test Voltage between Terminals	1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor	tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance	R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy	100000h at UN and 70℃,30000h at Urms

Application

*Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt

● Can bear large current, excellent heat dissipation

Product Picture

Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor 0

Product Shape

Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor 1

Workshop&Equipment

Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor 2

Exhibition

Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor 3

Certification

Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor 4

Packing Method

Alcon FP-11R-500 0.68uF CSP505 Induction Heating Capacitor 5
