Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor

Minimum Order Quantity : 20PCS Price : 112 USD/ PCS
Packaging Details : CARTON WITH FOAM BOX AND ANTI-CORRSION PROTECT. Delivery Time : 14 DAYS
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 1000 PCS/MONTH
Place of Origin: GUANGZHOU, CHINA. Brand Name: GDHY
Certification: SGS, ISO Model Number: C41701635KTE1501-01

Detail Information

BRAND: GDHY PLACE OF ORIGIN: GUANGZHOU, CHINA
SUPPLIER TYPE: ORIGINAL MANUFACTURER TYPE: WATER COOLED CAPACITOR
CHARACTERISTICS: WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION. CORE: IMPORTED COPPER FOIL
TERMINAL: COPPER CERTIFICATION: SGS, ISO
OPERATION TEMP: -40℃~85℃ CAPACITANCE: 6.3UF
TOLERANCE: ±10% RATED POWER: 500KVAR
RATED VOLTAGE: 700VAC DIMENSION: 88*71.5*60
LIFE EXPECTANCY: 100000h At UN And 70℃,30000h At Urms ADVANTAGE: KEEP LOW DF AND LONG LIFE EXPECTANCY
PRINTING METHOD: LASER MARKING APPLICATION: NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING
EXPERIENCE: OVER 22 YEARS INSTALLATION: THROUGH HOLE
High Light:

C500TW Pp Film Capacitor

,

Low ESL ESR Film Capacitor

,

6.3UF Pp Film Capacitor

Product Description

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 0C41-TE1 6.3UF 700VAC 10% ALCON FP 12-500H CELEM C500TW POLYPROPYLENE FILM CAPACITOR DIELECTRIC LOW ESR ESL PLASMA







Technical Parameter

Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃~85℃
Capacity Range 6.3μF
Power Range 500kVar
Rated Voltage 700VAC
Capacity Tolerance ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Application



Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.



Features



● Conduction water-cooled

Polypropylene dielectric

Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation



Product Picture

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 1



Product Shape

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 2

Production

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 3



Workshop & Equipment

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 4



Packing Method

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 5

Certification

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 6

Exhibition

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 7

Low ESL ESR 6.3UF CELEM C500TW Pp Film Capacitor 8
