High Voltage 0.44uF 2000V Resonant Capacitor

Contact Now

High Voltage 0.44uF 2000V Resonant Capacitor

Minimum Order Quantity :	1000PCS	Price :	8 USD/ PCS
Packaging Details :	plastic bag and carton	Delivery Time :	about 14 DAYS
Payment Terms :	Western Union, MoneyGram, T/T	Supply Ability :	10000 PCS

Place of Origin:	GUANGZHOU, CHINA	Brand Name:	GDHY
Certification:	SGS,ISO	Model Number:	C46-0.44UF/2000V

Detail Information
Place Of Origin:	Guangzhou, China	Supplier Type:	Original Manufacturer
Classification:	Polypropylene Film Capacitor	Model Number:	C46202444JPI01-01
Material:	Metallized Polypropylene Film	Operating Temperature Range:	-40℃～+85℃
Capacitance:	0.44uF
Highlight:	2000V Resonant Capacitor , 0.44uF Resonant Capacitor

Product Description

0.44uF 2000V, resonant Capacitor, high voltage capacitor

High Voltage 0.44uF 2000V Resonant Capacitor 0

Technical Parameter

Reference Standards	IEC61071 .GB/T17702
Capacitance range	0.06uF～8.0uF
Operating Temperature Range	-40℃~70℃(Max. +85℃)Tmax +85℃
Withstand Voltage	1.5 Un DC/10S
Rated Voltage	1200VDC-4000VDC
Capacity Tolerance	士5%(J)±10%(K)
Dissipation factor	tg6≤0.0005 C≤1uF f=10KHz at 20°C tgo≤0.0010 C≥1uF f=10KHz at 20°C
Insulation resistance	C≤0.33uF Rs≥15000MQ(at20°℃100VDC 60s) C>0.33 uF RsC≥5000S (at20°℃ 100VDC 60s)

Specification download: C46.pdf

Application

Widely used in series circuits or parallel resonant circuits of power electronic devices.
welding power supplies, induction heating equipment in resonance occasions.

Features

PET tape wrapping, epoxy resin perfusion
Tin plated copper nut or copper sheet leads.
High-frequency current capacity
Low ESL,low ESR
High pulse current , high dv/dt, high stability, self healing

Product picture

High Voltage 0.44uF 2000V Resonant Capacitor 1

Product shape

High Voltage 0.44uF 2000V Resonant Capacitor 3

Production

High Voltage 0.44uF 2000V Resonant Capacitor 4

Workshop& Equipment

High Voltage 0.44uF 2000V Resonant Capacitor 5

Packing method

High Voltage 0.44uF 2000V Resonant Capacitor 6

Certificate

High Voltage 0.44uF 2000V Resonant Capacitor 7

Exhibition

High Voltage 0.44uF 2000V Resonant Capacitor 8
