1.45uf 3000VDC GTO Snubber Protection Capacitor Power Electric Equipment
Contact Person : Roger Law
Phone Number : +86 189 8890 2989
WhatsApp : +8618988902989
| Minimum Order Quantity : | 50PCS | Price : | USD4.7 |
|---|---|---|---|
| Delivery Time : | 14DAYS | Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 1000PCS/MONTH |
| Place of Origin: | CHINA | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | C31102205JPC1-01 |
|
Detail Information |
|||
| Capacity: | 2uF | Voltage: | 1000VDC |
|---|---|---|---|
| Size(L*T*H): | 42.5*33*45MM | Application: | IGBT,UPS, Inverter, Induction Heating, Electric Welding Machine |
| Model: | C31102205JPC1-01 | Brand: | GDHY |
| Packing: | Plastic Case | Terminal: | Copper Sheet |
| Capacity Tolerance: | ±5%(J); ±10%(K) | Certification: | ISO,SGS |
| Material: | Polypropylnen Film | Series: | Resonant Capacitor |
| Place Of Original: | China | Color: | Gray |
| Encapsulation: | Flame Retardant Epoxy Encapsulation | ESR: | Low |
| Highlight: | Alcon KP-3C,WIMA MKP IGBT Snubber Capacitor,2UF IGBT Snubber Capacitor |
||
Product Description
| Reference Standards | IEC61071 .GB/T17702 |
| Operating Temperature Range | -40℃~+85℃ (Max. +105℃) |
| Capacity Range | 0.047μF -10μF |
| Rated Voltage | 700 VDC -3000VDC |
| Capacity Tolerance | ±5%(J); ±10%(K) |
| Withstand voltage | 1.5Un Dc/10S |
| Dissipation Factor | tgδ≤0.0005 C≤1μF f=10KHz Tgδ ≤ 0.0010 C≥1μF f=10KHz |
| Insulation Resistance | C≥0.33μF Rs≥30000MΩ(at20℃ 100VDC 60S) C>0.33 μF RsC≥10000S (at20℃ 100VDC 60S) |
| Flame Retardation | UL94V-0 |
| Life Expectancy | 100000hrs at Un and 85℃ |
Application
*IGBT buffer absorption circuit protection; IGBT buffer absorption device.
*Widely used in power electronic equipment UPS, inverter, induction heating, electric welding machine and other equipment peak voltage, peak current absorption protection
Features
● Plastic shell, flame-retardant epoxy encapsulation
● Tinned copper sheet extraction
● Resistance to high voltage, low dissipation factor
● Low ESL, low ESR, low temperature rise
● High pulse current, high dV/dt affordability
Product Picture
Product Shape
Product Process
Workshop&Equipment
Exhibition
Certification
Packing Method
