Product Details:
|
|
| Place of Origin: | GUANGZHOU, CHINA |
|---|---|
| Brand Name: | GDHY |
| Certification: | CQC, KC, VDE, UL, SGS ETC |
| Model Number: | C41601135KBB1301-01 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 20 PCS |
| Price: | USD 60/ PCS |
| Packaging Details: | CARTON WITH FOAM BOX AND ANIT-CORRISON PROTECT. |
| Delivery Time: | 14 DAYS |
| Payment Terms: | Western Union, T/T, MoneyGram |
| Supply Ability: | 1000PCS/MONTH |
|
Detail Information |
|||
| BRAND: | GDHY | PLACE OF ORIGIN: | GUANGZHOU, CHINA |
|---|---|---|---|
| SUPPLIER TYPE: | ORIGINAL MANUFACTURER | MODEL NUMBER: | C41601135KBB1301-01 |
| CHARACTERISTICS: | WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION. | CORE: | IMPORTED COPPER FOIL |
| TERMINAL: | COPPER | CERTIFICATION: | CQC, KC, VDE, UL, SGS ETC |
| OPERATION TEMP: | -40℃～85℃ | TOLERANCE: | ±10% |
| CAPACITANCE: | 1.32UF | RATED VOLTAGE: | 600V |
| RATED POWER: | 300KVAR | DIMENSION: | 50*50*36 |
| LIFE EXPECTANCY: | 100000h At UN And 70℃,30000h At Urms | ADVANTAGE: | KEEP LOW DF AND LONG LIFE EXPECTANCY |
| PRINTING: | LASER MARKING | APPLICATION: | WIDELY USED IN HIGH POWER AND HIGH FREQUENCY RESONANT DEVICES |
| EXPERIENCE: | OVER 22 YEARS | INSTALLATION: | THROUGH HOLE |
| High Light: | ALCON FP-5F-200,600VAC Water Cooled Capacitor,1.32UF Water Cooled Capacitor |
||
Product Description
C41-BB1 1.32UF/600V/300KVAR (ALCON FP-5F-200) HIGH FREQUENCY CAPACITOR HIGH POWER DEVICE
| Reference Standards | GB/T 3984-2004 IEC 60110.1 |
| Operating Temperature Range | -40℃～85℃ |
| Capacity Range | 1.32μF |
| Power Range | 300kVar |
| Rated Voltage | 600VAC |
| Capacity Tolerance | ±10% |
| Test Voltage between Terminals | 1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃ |
| Dissipation Factor | tgδ≤5×10-4 at 25℃±5℃,1kHz |
| Insulation Resistance | R•C≥3000s,at 100VDC,25℃±5℃,60s |
| Life Expectancy | 100000h at UN and 70℃,30000h at Urms |
Specification download: C41-BB1.pdf
Application
Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.
Feature
● Conduction water-cooled
● Polypropylene dielectric
● Low dissipation factor(tgδ), low ESL, low ESR
● High voltage, high frequency and high dV/dt
● Can bear large current, excellent heat dissipation
Product Picture
Product shape
Production
Workshop& Equipment
Packing method
Certificate
Exhibition
