Product Details:
|
|
Place of Origin: | China |
---|---|
Brand Name: | GDHY |
Certification: | ISO,SGS |
Model Number: | C41601135KBB1201-01 |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 20pcs |
Price: | USD60 |
Delivery Time: | 14days |
Payment Terms: | T/T, Western Union, MoneyGram |
Supply Ability: | 1000PCS/MONTH |
Detail Information |
|||
Capacity: | 1.3uF | Voltage: | 600VAC |
---|---|---|---|
Size: | 50mm*50mm*36mm | Power: | 200KVAR |
Frequency: | 100-170kHz | Model: | C41601135KBB1201-01 |
Brand: | GDHY | Terminal: | Copper |
Capacity Tolerance: | ±5% ~ ±10% | Material: | Polypropylnen Film&Copper |
Series: | High Frequency Capacitor | Place Of Original: | China |
Max Irms: | 650A | Application: | Induction Heating, Heat Treatment, Plasma Applications, Resonant Circuits, Medical Imaging, Wireless Power Transfer, EV (electric Vehicle) Charging, IPT, High Frequency Inverters,etc. |
High Light: | Alcon FP-5F-200,1uF Induction Heater Capacitor,1000VAC Induction Heater Capacitor |
Product Description
Reference Standards | GB/T 3984-2004 IEC 60110.1 |
Operating Temperature Range | -40℃~85℃ |
Capacity Range | 0.33μF~2.4μF |
Power Range | 300kVar-400 kVar |
Rated Voltage | 400-1000VAC |
Capacity Tolerance | ±5% ~ ±10% |
Test Voltage between Terminals | 1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃ |
Dissipation Factor | tgδ≤5×10-4 at 25℃±5℃,1kHz |
Insulation Resistance | R•C≥3000s,at 100VDC,25℃±5℃,60s |
Life Expectancy | 100000h at UN and 70℃,30000h at Urms |
Application
Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.
Feature
● Conduction water-cooled
● Polypropylene dielectric
● Low dissipation factor(tgδ), low ESL, low ESR
● High voltage, high frequency and high dV/dt
● Can bear large current, excellent heat dissipation
Product Picture
Product Shape
Workship&Equipment
Exhibiton
Certification
Packing Method
