TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor

Contact Now

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor

Minimum Order Quantity :	100PCS	Price :	USD0.7/PC
Delivery Time :	14DAYS	Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	1000PCS/MONTH

Place of Origin:	CHINA	Brand Name:	GDHY
Certification:	ISO,SGS	Model Number:	C52801104JX08-01

Detail Information
Capacity:	0.1uF	Voltage:	800VDC
Size(WTH):	187.513.5mm	Pitch:	15mm
Model:	C52801104JX08-01	Brand:	GDHY
Packing:	Plastic Case	Terminal:	CP Wire
Capacity Tolerance:	Guangzhou	Certification:	ISO,SGS
Material:	Polypropylnen Film	Series:	DC-LINK Capacitor
Place Of Original:	China	Color:	Yellow
Encapsulation:	Flame Retardant Epoxy Resin	Application:	UPS, Inverter Power Supplies, Welder Power Supplies,Electric Vehicles
High Light:	800VDC Power Supply Capacitor , 0.1uF Power Supply Capacitor , TDK B32774 MKP

Product Description

C52 0.1uF 800VDC DC-LINK CAPACITOR POWER SUPPLY CAPACITOR TDK B32774 MKP DC LINK CAPACITOR

Technical Parameter

Reference Standards	GB/T 17702, IEC 61071
Operating Temperature Range	-40℃～85℃
Capacity Range	5.0μF ~ 90μF
Rated Voltage	500VDC~1200VDC
Capacity Tolerance	±5%(J); ±10%(K)
Test Voltage between Terminals	1.5UN(DC)60S 25℃±5℃
Test Voltage btw Terminals & Case	1000+2×UN/√2(VAC) 50Hz 60S (min 3000VAC)
Dissipation Factor	tgδ≤1.5×10-3 at 25℃±5℃,100Hz
Insulation Resistance	C•R≥5000S,at 100VDC,25℃±5℃,60S
Life Expectancy	100000h at Ur and ≤70℃

Application

● Widely used in DC-Link Circuits as a filter for Energy Storage.

● Ups, Inverter Power Supplies, Welder Power Supplies, etc.

Feature

● Polypropylene film dielectric

● Plastic shell, flame retardant epoxy resin encapsulation

● Tin coated copper wire

● High pulse current withstand capacity

● Convenient installation

Product Picture

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor 0

Production Shape

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor 1

Production Process

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor 2

Workshop& Equipment

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor 3

Company Exhibition

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor 4

Certification

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor 5

Packing Method

TDK B32774 MKP 800VDC 0.1uF Power Supply Capacitor 6
