GDHY CBB28-682J1250V-10RN-1R for High Frequency Direct Current And Pulse Circuits

Contact Now

GDHY CBB28-682J1250V-10RN-1R for High Frequency Direct Current And Pulse Circuits

Minimum Order Quantity :	10KPCS	Price :	0.08 USD/ PCS
Packaging Details :	plastic bag and carton	Delivery Time :	14 DAYS
Payment Terms :	Western Union, MoneyGram, T/T	Supply Ability :	1000 KPCS

Place of Origin:	GUANGZHOU, CHINA	Brand Name:	GDHY
Certification:	VDE, ISO	Model Number:	CBB28-682J1250V-10RN-1R

Detail Information
Place Of Origin:	Guangzhou, China	Supplier Type:	Original Manufacturer
Classification:	Polypropylene Film Capacitor	Model Number:	C6821250-D-10-1R
Material:	Metallized Polypropylene Film	Operating Temperature Range:	-40℃～85℃
Capacitance:	0.0068UF	Capacity Tolerance:	±5%
Rated DC Voltage:	1250VDC	Wmax:	13mm
Hmax:	6.5mm	Tmax:	10.5mm
Pitch:	10mm±1.5mm
High Light:	CBB28-682J1250V-10RN-1R , Self healing Polypropylene Film Capacitor , CBB28-682J1250V-10RN-1R For High Frequency

Product Description

GDHY CBB28-682J1250V-10RN-1R; Widely used in high frequency, direct current and pulse circuits

GDHY CBB28-682J1250V-10RN-1R for High Frequency Direct Current And Pulse Circuits 0 CBB28-682J1250V-10RN-1R

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40°℃~85°℃
Capacitance range	0.001 uF～0.68 uF
Rated Voltage	100VDC,250VDC,400VDC,630VDC,1250VDC
Capacitance Tolerance	士5%(J);±10%(K);±20%(M)
Withstand voltage	2UN 5S (at20士5°℃)
Insulation Resistance	≥30000MQ(at 20°℃ 100VDC 1Min)

Specification download: CBB28.pdf

Application

Widely used in high frequency, direct current and pulse circuits

Features

Metallized polypropylene inner series structure
Self-healing
lt can be bear high voltage
Flame retardant epoxy resin wrapping

Product picture

GDHY CBB28-682J1250V-10RN-1R for High Frequency Direct Current And Pulse Circuits 1

Product shape

GDHY CBB28-682J1250V-10RN-1R for High Frequency Direct Current And Pulse Circuits 2

Production

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 3

Workshop& Equipment

GDHY CBB28-682J1250V-10RN-1R for High Frequency Direct Current And Pulse Circuits 4

Packing method

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

Certificate

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 6

Exhibition

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
