FP-4-150-SM/SP GDHY Capacitor

Minimum Order Quantity :	20 PCS	Price :	107 USD /PCS
Packaging Details :	CARTON PACKING WITH FOAM BOX AND ANTI-CORRSION PROTECT.	Delivery Time :	14 DAYS
Payment Terms :	T/T, Western Union, MoneyGram	Supply Ability :	1000 PCS/ MONTH

Place of Origin:	GUANGZHOU, CHINA.	Brand Name:	GDHY
Certification:	SGS,ISO	Model Number:	C41701334KTC2151-01

Detail Information
BRAND NAME:	GDHY	MODEL NUMBER:	C41701334KTC2151-01
CORE:	IMPORTED COPPER FOIL	MATERIAL:	COPPER
INSTALLATION:	THROUGH HOLE	CAPACITANCE VALUE:	0.33UF
RATED POWER:	150KVAR	RATED VOLTAGE:	700V
OPERATION TEMPERATURE:	-40℃～85℃	CERTIFICATION:	CQC, KC, VDE, UL, SGS ETC
CAPACITY TOLERANCE:	±10%	DIMENSION:	683030.2MM
LIFE EXPECTANCY:	100000h At UN And 70℃,30000h At Urms	LEAD EKECTRODE:	COPPER
ADVANTAGE:	KEEP LOW DF AND LONG LIFE EXPECTANCY	SHAPE:	SQAURE
PRINTING METHOD:	LASER MARKING	QUALITY CERTIFICATE:	ISO 9001
APPLICATION FIELD:	NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING	COMPANY HISTORY:	SINCE 1998
Highlight:	FP-4-150-SM/SP , GDHY Capacitor , GDHY Conduction Cooled Capacitor

Product Description

FP-4-150-SM/SP GDHY Capacitor 0 C41-TC2 0.33UF/700V/150KVAR ALCON FP-4-150-SM/SP CELEM CSM150 QUALITY CAPACITORS FILM CAPACITOR HIGH POWER CAPACITORS

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Operating Temperature Range	-40℃～85℃
Capacity Range	0.33μF
Power Range	150 kVar
Rated Voltage	700VAC
Capacity Tolerance	±10%
Test Voltage between Terminals	1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor	tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance	R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy	100000h at UN and 70℃,30000h at Urms

Application

Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation

Product Picture

FP-4-150-SM/SP GDHY Capacitor 1

Specification download: C41-TC2.pdf

Product Shape

FP-4-150-SM/SP GDHY Capacitor 2

Production Line

FP-4-150-SM/SP GDHY Capacitor 3

Workshop&Equipment

FP-4-150-SM/SP GDHY Capacitor 4

Packing Method

FP-4-150-SM/SP GDHY Capacitor 5

Certification

FP-4-150-SM/SP GDHY Capacitor 6

Exhibition

FP-4-150-SM/SP GDHY Capacitor 7
