0.22uf 1200VDC DC Link Coupling Film Capacitor Filter
Contact Person : Roger Law
Phone Number : +86 189 8890 2989
WhatsApp : +8618988902989
| Minimum Order Quantity : | 200PCS | Price : | PLEASE CONTACT US FOR DETAILS |
|---|---|---|---|
| Packaging Details : | PLASTIC BAG | Delivery Time : | 15 WORKING DAYS |
| Payment Terms : | T/T, Western Union, MoneyGram | Supply Ability : | MORE THAN 1KPCS/MONTH |
| Place of Origin: | GUANGZHOU, CHINA | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | C52 1.0UF/400V |
|
Detail Information |
|||
| Features: | Plastic Shell, Dry Resin Infusion | Brand: | GDHY |
|---|---|---|---|
| Supplier Type: | Original Manufacturer | Type: | DC-LINK Capacitor |
| Dielectric: | Polypropylene (MKP) | Capacitance: | 1.0UF |
| Rated Voltage: | 400V | Advantage: | Replace Electrolytic Capacitors, Better Performance And Longer Life |
| Terminals: | Tinned Copper Wire | Certification: | ISO,SGS |
| Applications: | Wind Power Converter, UPS, Etc | ||
| Highlight: | MKP DC Link Capacitors,C52 1.0uf 400V DC Link Capacitors,1.0UF DC LINK Film Capacitors |
||
Product Description
| Reference Standards | GB/T 17702 IEC 61071 |
| Model code | C52401105JX08-01 |
| Capacitance | 1.0μF |
| Rated Voltage | 400V |
| Max. operating temperature | 105℃ |
| Tolerance | ±5%(J) |
| Flame retardation | UL94V-0 |
| Dissipation Factor (DF) | tgδ≤1.5X 10-3 ( at25℃±5℃, 100Hz) |
| Insulation Resistance | C•R≥5000S (at100VDC,at25℃±5℃,1Min) |
| Life Expectancy | 100000h at UN and ≤70℃ |
Datasheet download:C52.pdf
Application
● Widely used in DC-Link circuits to store energy. Take electric vehicle applications as example, the DC link capacitor is used as a load-balacing energy storage device.
● Also used in UPS, Pvinverter, wind power converter, charging pile, all kinds of frequency converter and inverter power supply; Pure electric and hybrid cars, etc.
● This capacitor can replace electrolytic capacitors, its life expectancy is longer and has better performance.
Feature
● Metallized polypropylene film as the electrode
● Dry resin infusion
● Encapsulated in square plastic case
● Tinned copper wire
● High pulse current and high dv/dt; low ESL/ESR
Product Picture
Production Shape
Production Process
Workshop& Equipment
Company Exhibition
Certification
Packing Method
