224nF Metallized Film Capacitors 630VDC 15MM Pitch
Contact Person : Roger Law
Phone Number : +86 189 8890 2989
WhatsApp : +8618988902989
| Minimum Order Quantity : | 10KPCS | Price : | 0.1 USD/ PCS |
|---|---|---|---|
| Packaging Details : | plastic bag and carton | Delivery Time : | 14 DAYS |
| Payment Terms : | Western Union, MoneyGram, T/T | Supply Ability : | 1000 KPCS |
| Place of Origin: | GUANGZHOU, CHINA | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | CBB22-104J630V-15RN-1R |
|
Detail Information |
|||
| Place Of Origin: | GUANGZHOU, CHINA | Supplier Type: | ORIGINAL MANUFACTURER |
|---|---|---|---|
| Type: | POLYPROPYLENE FILM CAPACITOR | Model Number: | B1040630-D-15-1R |
| Material: | Metallized Polypropylene Film | Operating Temperature Range: | -40℃～85℃ |
| Capacitance: | 0.1UF | Capacity Tolerance: | ±5% |
| Rated DC Voltage: | 630VDC | Pitch: | 10±1.5mm |
| Height: | 8mm | Width: | 13mm |
| Thickness: | 12.5mm | ||
| Highlight: | CBB22 104J630VDC Polypropylene Film Capacitor,Low Dielectric Absorption Polypropylene Film Capacitor |
||
Product Description
CBB22 104J630VDC ,very low dielectric absorption,Polypropylene Film Capacitor
| Reference Standards | GB/T 10190(IEC 60384-16) |
| Climate Category | 40/085/21 |
| Operating Temperature Range | -40°℃~85°℃ |
| Capacity Range | 0.1μF |
| Rated Voltage | 630VDC |
| Capacity Tolerance | ±5% |
| Withstand voltage | Vtet:1.6UN 5S (at20±5℃) |
| Insulation Resistance |
C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min) C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min) |
Specification download: CBB22.pdf
Application
Widely used in High Frequency, DC, AC, Pulse Circuits. S-correction circuits of the display device
Features
● Metallized polypropylene film dielectric
● Non-inductive winding structure
● Flame retardant epoxy resin powder encapsulation
● Resistance to high voltage, small tg6,low temperature rise
Product picture
Product shape
Production
Workshop& Equipment
Packing method
Certificate
Exhibition
