224nF Metallized Film Capacitors 630VDC 15MM Pitch
Contact Person : Roger Law
Phone Number : +86 189 8890 2989
WhatsApp : +8618988902989
| Minimum Order Quantity : | 100Kpcs | Price : | USD0.25/PC |
|---|---|---|---|
| Packaging Details : | PLASTIC BAG | Delivery Time : | 14days |
| Payment Terms : | T/T, Western Union, MoneyGram | Supply Ability : | 1KKpcs/Month |
| Place of Origin: | China | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | CBB22 104/400V 10 |
|
Detail Information |
|||
| Capacity: | 0.1uF | Voltage: | 400V |
|---|---|---|---|
| Size(W*T*H): | 13*9*4.5mm | Pitch: | 10mm |
| Model: | CBB22 104/400V 10 | Name: | CBB22 104J400V 10 |
| Brand: | GDHY | Terminal: | CP Wire |
| Capacity Tolerance: | ±5% ~ ±10% | Material: | Polypropylnen Film |
| Series: | CBB Polypropylene Film Capacitor | Place Of Original: | China |
| Supplier Type: | Manufacturer | Lead: | 0.6mm |
| Color: | Brown | Encapsulation: | Power |
| Packaging Type: | Through Hole | Application: | Disinfection Cabinet,Stove Igniter,Water Heater |
| Highlight: | P10mm CBB22 Film Capacitor,400V CBB22 Film Capacitor,CBB22 104J400V 10 |
||
Product Description
P10mm CBB Polypropylene Film Capacitor For Disinfection Cabinet,Stove Igniter,Water Heater
| Reference Standards | GB/T 10190(IEC 60384-16) |
| Climate Category | 40/085/21 |
| Operating Temperature Range | -40℃～+85℃ |
| Capacity Range | 0.01～2.2μF |
| Rated Voltage | 100V,250V,400V,630V(DC) |
| Capacity Tolerance | ±5%(J)；±10%(K)；±20%(M) |
| Withstand voltage | 2.0UR 5S (@20±5%) |
| Dissipation Factor | tgδ≤0.0010 (@20℃, 1KHz) |
| Insulation Resistance |
≥30000MΩ(at 20℃ 100VDC 1Min) |
Application
Widely used in high frequency, direct current and pulse circuits
Features
● Metallized polypropylene inner series structure
● Self-healing
● It can be bear high voltage
● Flame retardant epoxy resin wrapping
Datasheet CBB22.pdf
Product Picture
Product Shape
Produce Line
Workshop&Equipment
Exhibition
Certification
Packing Method
