400KVar Water Cooled Capacitor

Product Details:
Place of Origin: China
Brand Name: GDHY
Certification: ISO,SGS
Model Number: C41102664KBB2401-01
Payment & Shipping Terms:
Minimum Order Quantity: 20pcs
Price: USD30/PC
Delivery Time: 14days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000PCS/ MONTH

Detail Information

Capacity: 0.66uF Voltage: 1000VAC
Size: 80mm*80mm*36mm Power: 400KVAR
Frequency: 95-216KHZ Model: C41102664KBB2401-01
Capacity Tolerance: ±5% ~ ±10% Material: Polypropylnen Film&Copper
Series: Water Cooled Capacitor Place Of Original: China
Max Irm: 600A Application: Induction Heating, Heat Treatment, Plasma Applications, Resonant Circuits, Medical Imaging, Wireless Power Transfer, EV (electric Vehicle) Charging, IPT, High Frequency Inverters,etc.
High Light:

Alcon FP-7-300


400KVar Water Cooled Capacitor


1000V Metallized Polyester Film Capacitor

Product Description

C41-BB2 0.66uF 1000V 400KVar Alcon FP-7-300 for induction melting machine Water Cooled Capacito


Technical Parameter

Reference Standards GB/T 3984-2004 IEC 60110.1
Operating Temperature Range -40℃~85℃
Capacity Range 0.33μF~4μF
Power Range 300~400kVar
Rated Voltage 400-1100VAC
Capacity Tolerance ±5% ~ ±10%
Test Voltage between Terminals 1.5UNAC 10s
2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms




Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.




● Conduction water-cooled

Polypropylene dielectric

Low dissipation factor(tgδ), low ESL, low ESR

● High voltage, high frequency and high dV/dt,

● Can bear large current, excellent heat dissipation



Product Picture


400KVar Water Cooled Capacitor 0


Product Shape


400KVar Water Cooled Capacitor 1




400KVar Water Cooled Capacitor 2



400KVar Water Cooled Capacitor 3



400KVar Water Cooled Capacitor 4


Packing Method


400KVar Water Cooled Capacitor 5
