| Minimum Order Quantity : | 20PCS | Price : | 112 USD/ PCS |
|---|---|---|---|
| Packaging Details : | CARTON WITH FOAM BOX AND ANTI-CORRSION PROTECT. | Delivery Time : | 14 DAYS |
| Payment Terms : | T/T, Western Union, MoneyGram | Supply Ability : | 1000 PCS/MONTH |
| Place of Origin: | GUANGZHOU, CHINA. | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | C41751305KTE1501-01 |
|
Detail Information |
|||
| BRAND: | GDHY | PLACE OF ORIGIN: | GUANGZHOU, CHINA |
|---|---|---|---|
| SUPPLIER TYPE: | ORIGINAL MANUFACTURER | TYPE: | WATER COOLED CAPACITOR |
| CHARACTERISTICS: | WATER COOLED, CONDUCTION COOLED, EXCELLENT HEAT DISSPATION. | CORE: | IMPORTED COPPER FOIL |
| TERMINAL: | COPPER | CERTIFICATION: | CQC, KC, VDE, UL, SGS,UL ETC |
| OPERATION TEMP: | -40℃～85℃ | CAPACITANCE: | 3UF |
| TOLERANCE: | ±10% | RATED POWER: | 500KVAR |
| RATED VOLTAGE: | 750VAC | DIMENSION: | 88*71.5*60 |
| LIFE EXPECTANCY: | 100000h At UN And 70℃,30000h At Urms | ADVANTAGE: | KEEP LOW DF AND LONG LIFE EXPECTANCY |
| PRINTING METHOD: | LASER MARKING | APPLICATION: | NEW ENERGY FIELDS; TRANSPORTATION FACILITIES; HIGH POWER INDUSTRIAL FACILITIES: QUALITY CONTROL: IQC, SPC, INSPECTION, WAREHOUSING |
| EXPERIENCE: | OVER 22 YEARS | INSTALLATION: | THROUGH HOLE |
| Highlight: | 3UF Induction Heating Capacitor,750VAC Induction Heating Capacitor,300nF Induction Capacitor |
||
Product Description
C41-TE1 3UF 750VAC 10% ALCON FP 12-500H CELEM C500TW US POWER CAPACITORS BILLET HEATING CAPACITOR INDUCTION HEAT MACHINE
| Reference Standards | GB/T 3984-2004 IEC 60110.1 |
| Operating Temperature Range | -40℃～85℃ |
| Capacity Range | 3μF |
| Power Range | 500kVar |
| Rated Voltage | 750VAC |
| Capacity Tolerance | ±10% |
| Test Voltage between Terminals | 1.5UNAC 10s 2~3.5UNDC 10s at 25℃±5℃ |
| Dissipation Factor | tgδ≤5×10-4 at 25℃±5℃,1kHz |
| Insulation Resistance | R•C≥3000s,at 100VDC,25℃±5℃,60s |
| Life Expectancy | 100000h at UN and 70℃,30000h at Urms |
Application
Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc.
Features
● Conduction water-cooled
● Polypropylene dielectric
● Low dissipation factor(tgδ), low ESL, low ESR
● High voltage, high frequency and high dV/dt,
● Can bear large current, excellent heat dissipation
Product Picture
Product Shape
Production
Workshop & Equipment
Packing Method
Certification
Exhibition
