| Minimum Order Quantity : | 10Kpcs | Price : | USD0.8/PC |
|---|---|---|---|
| Delivery Time : | 14days | Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 1KKpcs/Month |
| Place of Origin: | China | Brand Name: | GDHY |
|---|---|---|---|
| Certification: | SGS,ISO | Model Number: | CBB20 2.2UF 400V/XXP 225J400V |
|
Detail Information |
|||
| Capacity: | 2.2uF | Voltage: | 400VDC |
|---|---|---|---|
| Size: | 22mm*44mm | Model: | CBB20 2.2UF 400V/XXP 225J400V |
| Brand: | GDHY | Terminal: | CP Wire |
| Capacity Tolerance: | ±5% ~ ±10% | Place Of Original: | China |
| Supplier Type: | Manufacturer | Lead: | 0.8mm |
| Color: | Yellow/White/Red | Encapsulation:: | Flame Retardant Epoxy Resin |
| Print: | Ink/ Laser | Application: | Temperature Compensating Circuit /Timing Oscillation Circuit /Audio Frequency Division Circuit |
| Highlight: | 2.2UF 400VDC Axial Film Capacitor,2.2UF Metallized Polypropylene Film Capacitor,400V/XXP 225J400V |
||
Product Description
| Reference Standards | GB/T 10190(IEC 60384-16) |
| Climate Category | 40/085/21 |
| Operating Temperature Range | -40℃～85℃ Tmax 105℃ |
| Capacity Range | 0.01～40μF |
| Rated Voltage | 250VDC/400VDC/630VDC |
| Capacity Tolerance | ±5%(J)；±10%(K)；±20%(M) |
| Withstand voltage | 1.6UR (5S) |
| Dissipation Factor | tgδ≤0.0010 (20℃, 1KHz) |
| Insulation Resistance | C≤0.33μF R≥100000MΩ(at 20℃ 100VDC 1Min) C>0.33 μF RCN≥30000S (at 20℃ 100VDC 1Min) |
Application
Temperature compensating circuit
Timing oscillation circuit
Audio frequency division circuit
Features
● Metallized polypropylene film dielectric
● Non-inductive winding structure
● Myla tape with flame retardant epoxy resin at both ends
● Axial tin copper wire leads
● Resistance to high voltage, small tgδ, low temperature rise
Product Picture
Product Shape
Workshop&Equipment
Exhibitoon
Certification
Packign Method
