1uF 1000VDC Resonant Capacitor

Product Details:
Place of Origin: CHINA
Brand Name: GDHY
Certification: ISO,SGS
Model Number: C42-0.36UF/3000V
Payment & Shipping Terms:
Minimum Order Quantity: 5KPCS
Price: USD3/PC
Delivery Time: 14DAYS
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000PCS/MONTH

Detail Information

Capacity: 0.36uF Voltage: 3000VDC
Application: Switching Device In Power Electronics Model: C42302364JP34-01
Brand: GDHY Packing: Plastic Case
Terminal: CP Wire Capacity Tolerance: ±5%(J); ±10%(K)
Certification: ISO,SGS Material: Polypropylnen Film
Series: Resonant Capacitor Place Of Original: China
High Light:

1uF 1000VDC Resonant Capacitor


Resonant Polypropylene Film Capacitor


1000nf Resonant Capacitor

Product Description

1uF 1000VDC Resonant Capacitor 0


Technical Parameter

Reference Standards GB/T 17702 IEC 61071
Operating Temperature Range Max.Operating temperature,Top max:+105℃
Upper category temperature:+85℃
Lower category temperature:-40℃
Capacity Range 0.1μF~8.0μF
Rated Voltage 400VDC~3000VDC
Capacity Tolerance ±5%(J); ±10%(K)
Test Voltage between Terminals 1.5Ur(DC)60S 20℃
Test Voltage btw Terminals & Case 1000+2×Ur/√2(VAC) 50Hz 60S(1min 3000V)
Dissipation Factor tgδ≤0.0005 C≤1μF f=10KHz at 20℃
tgδ≤0.0010 C≥1μF f=10KHz at 20℃
Insulation Resistance C≤0.33μF Rs≥15000MΩ(20℃ 100VDC 60S)
C>0.33 μF RsC≥5000S (20℃ 100VDC 60S)
Flame Retardation UL94V-0
Life Expectancy 100000hrs ( Ur hotspot ≤ 85℃)





● Widely used in series circuits or parallel resonant circuits of power electronic devices.

● Also applied to the peak voltage of the switching device in power electronics, peak current absorption protection.




● Plastic shell encapsulation, epoxy resin sealed

●Tinned copper wire, small size, easy installation

● High voltage resistance, small dissipation factor (tgδ)

● Low ESL and ESR, low temperature rise

● High pulse current, high dV/dt, high stability, self healing


Product Picture

1uF 1000VDC Resonant Capacitor 11uF 1000VDC Resonant Capacitor 21uF 1000VDC Resonant Capacitor 3




Product Shape

1uF 1000VDC Resonant Capacitor 4



Product Process


1uF 1000VDC Resonant Capacitor 5




1uF 1000VDC Resonant Capacitor 6




1uF 1000VDC Resonant Capacitor 7




1uF 1000VDC Resonant Capacitor 8


Packing Method


1uF 1000VDC Resonant Capacitor 9
