0.66UF 700VAC Water Cooled Resonant Capacitor High Pulse

Contact Now

0.66UF 700VAC Water Cooled Resonant Capacitor High Pulse

Minimum Order Quantity :	100PCS	Price :	22 USD/ PCS
Packaging Details :	plastic bag and carton	Delivery Time :	14 DAYS
Payment Terms :	Western Union, MoneyGram, T/T	Supply Ability :	1000 PCS

Place of Origin:	GUANGZHOU, CHINA	Brand Name:	GDHY
Certification:	VDE	Model Number:	C41-TC2-0.66uF/700VAC

Detail Information
Place Of Origin:	Guangzhou, China	Supplier Type:	Original Manufacturer
Classification:	Polypropylene Film Capacitor	Model Number:	C41701664KTC2201-01
Material:	Metallized Polypropylene Film	Operating Temperature Range:	-40℃～+85℃
Capacitance:	0.66UF	Length:	68mm
Height:	30mm	Thickness:	30.2mm
Max Power:	200kVar	Max Irms:	400A
Rated Voltage:	700Vrms
High Light:	700VAC Water Cooled Resonant Capacitor , 0.66UF Water Cooled Resonant Capacitor

Product Description

0.66UF 700VAC, Water Cooled Resonant Capacitor, Conduction Cooled, High Pulse

0.66UF 700VAC Water Cooled Resonant Capacitor High Pulse 0

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Capacitance range	0.1uF～85uF
Operating Temperature Range	-40°℃~85°℃
Rated Capacitance	100kVar-1500 kVar
Rated Voltage	400VAC-1100VAC
Capacity Tolerance	士5%±10%
Dissipation factor	tg6≤5×10-4 at 25℃土5℃,1kHz
Insulation resistance	R·C≥3000s, at 100VDC,25℃土5℃,60s

Specification download: C41-TC2.pdf

Application

Widely used in high power and high frequency resonant devices

Features

Conduction water-cooled
Polypropylene dielectric
Low dissipation factor(tg6),low ESL and low ESR
High voltage, high frequency and high dv/dt
High current resistance, excellent heat dissipation

Product picture

0.66UF 700VAC Water Cooled Resonant Capacitor High Pulse 1

Product shape

0.66UF 700VAC Water Cooled Resonant Capacitor High Pulse 4

Production

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 3

Workshop& Equipment

0.66UF 700VAC Water Cooled Resonant Capacitor High Pulse 6

Packing method

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

Certificate

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 6

Exhibition

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
