0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating
0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating
Contact Now

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating

Minimum Order Quantity : 30 PCS Price : PLEASE CONTACT US FOR DETAILS
Packaging Details : CARTON WITH FOAM BOX AND ANIT-CORRISON PROTECT. Delivery Time : 14 DAYS
Payment Terms : Western Union, MoneyGram, T/T Supply Ability : 1000 PCS / MONTH
Place of Origin: GUANGZHOU, CHINA Brand Name: GDHY
Certification: SGS, ISO Model Number: C41701664KBB2301-01

Detail Information
CAPACITY: 0.66μF/664 RATED VOLTAGE: 700VRMS
TOLERANCE: ±10% DIMENSION: 80*80*36MM
DIELECTRIC: POLYPROPYLENE MAX IRMS: 500A
MAX POWER: 300KVAR ESR: 0.8mΩ
High Light:

700V Water Cooled Capacitors

,

C41 Water Cooled Capacitors

,

0.66UF Water Cooled Capacitors

Product Description

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 0WATER COOLING CAPACITOR 0.66UF 664 700V HIGH FREQUENCY HIGH POWER RESONANT CAP



Technical Parameter



Reference Standards GB/T 3984-2004 IEC 60110.1
Capacity 0.66μF
Rated Voltage 700Vrms
Model Number C41701664KBB2301-01
Max Power 300kVar
Capacity Tolerance ±10%
ESR mΩ 0.8 mΩ
Operating Temperature Range -40℃～+85℃
Dimension 80*80*36mm
Test Voltage between Terminals 1.5UNAC 10s
3.5UNDC 10s at 25℃±5℃
Dissipation Factor tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy 100000h at UN and 70℃,30000h at Urms



Application



Widely used in high power and high frequency resonant devices.

Can be used in applications including induction heating, RF Amplifiers, welding equipment, heat treatment, medical imaging, wireless charging , electric vehicle charging, etc.

For replace Celem power capacitors.



Feature



● Conduction cooled

● Low dissipation factor(tgδ), ESL and  ESR

● High voltage, high frequency and high dV/dt; high current resistance

● Excellent heat dissipation

● Self healing, maximum operating core temperature 85℃

● High thermal withstand capacity

● Threaded hole for mounting on bus-bar



Product Picture

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 10.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 2



Product shape

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 3



Production

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 4



Workshop& Equipment

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 5



Packing method

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 6

Certificate

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 7

Exhibition

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 8

0.66UF 700V Water Cooled Capacitors C41 High Power High Thermal Withstand Inductive Heating 9
