0.56UF 630VDC CBB22-564J630V-20RN-1R Polypropylene Film Capacitor

Contact Now

0.56UF 630VDC CBB22-564J630V-20RN-1R Polypropylene Film Capacitor

Minimum Order Quantity :	10KPCS	Price :	0.02 USD/ PCS
Packaging Details :	plastic bag and carton	Delivery Time :	14 DAYS
Payment Terms :	Western Union, MoneyGram, T/T	Supply Ability :	1000 KPCS

Place of Origin:	GUANGZHOU, CHINA	Brand Name:	GDHY
Certification:	VDE, ISO	Model Number:	CBB22-564J630V-20RN-1R

Detail Information
Place Of Origin:	GUANGZHOU, CHINA	Supplier Type:	ORIGINAL MANUFACTURER
Type:	POLYPROPYLENE FILM CAPACITOR	Model Number:	B5640630-D-20-1R
Material:	Metallized Polypropylene Film	Operating Temperature Range:	-40℃～85℃
Capacitance:	0.56UF	Capacity Tolerance:	±5%
Rated DC Voltage:	630VDC
High Light:	0.56UF Polypropylene Film Capacitor , 630VDC Polypropylene Film Capacitor , CBB22-564J630V-20RN-1R Capacitor

Product Description

0.56UF 630VDC; Model Name: CBB22 564J630V 20RN ; It Feature Well Stability

0.56UF 630VDC CBB22-564J630V-20RN-1R Polypropylene Film Capacitor 0 CBB22-564J630V-20RN-1R

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40°℃~85°℃
Capacity Range	0.56μF
Rated Voltage	630VDC
Capacity Tolerance	±5%
Withstand voltage	Vtet:1.6UN 5S (at20±5℃)
Insulation Resistance	C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min) C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min)

Application

Widely used in High Frequency, DC, AC, Pulse Circuits. S-correction circuits of the display device

Features

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tg6,low temperature rise

Product picture

0.56UF 630VDC CBB22-564J630V-20RN-1R Polypropylene Film Capacitor 1

Product shape

0.56UF 630VDC CBB22-564J630V-20RN-1R Polypropylene Film Capacitor 2

Production

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 3

Workshop& Equipment

0.56UF 630VDC CBB22-564J630V-20RN-1R Polypropylene Film Capacitor 4

Packing method

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 5

Certificate

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 6

Exhibition

MKP-X2 0.33UF/310V P22.5 WIMA FKP 2/FKP 3 KEMET R4631/R463R/R463W/R463N TDK B32669 VISHAY F339M-X2 SAFETY CAPACITOR 7
