104nF Axial Audio Film Capacitor Metallized Polypropylene 630VDC CBB20
Contact Person : Cecilia
Phone Number : +86 18922170847
WhatsApp : +8618922170847
Minimum Order Quantity : | 10KPCS | Price : | 0.1 USD/ PCS |
---|---|---|---|
Packaging Details : | plastic bag and carton | Delivery Time : | 14 DAYS |
Payment Terms : | Western Union, MoneyGram, T/T | Supply Ability : | 1000 KPCS |
Place of Origin: | GUANGZHOU, CHINA | Brand Name: | GDHY |
---|---|---|---|
Certification: | VDE, ISO | Model Number: | CBB20-0.1UF/630V |
Detail Information |
|||
Place Of Origin: | Guangzhou, China | Supplier Type: | Original Manufacturer |
---|---|---|---|
Classification: | Polypropylene Film Capacitor | Model Number: | CBB20631104JX10-01 |
Material: | Metallized Polypropylene Film | Operating Temperature Range: | -40℃~85℃ |
Capacitance: | 0.1UF | Capacity Tolerance: | ±5% |
Rated DC Voltage: | 630VDC | OD: | 11mm |
L: | 27mm | ||
High Light: | 0.1UF Tubular Film Capacitor,630VDC Tubular Film Capacitor,11mm Axial Audio Film Capacitor |
Product Description
0.1UF 630VDC, Axial Leads And Tubular Film Capacitor, Audio Frequency Circuits
Reference Standards | GB/T 10190(IEC 60384-16) |
Climate Category | 40/085/21 |
Operating Temperature Range | -40°℃~85°℃ |
Capacitance | 0.1μF |
Rated Voltage | 630VDC |
Capacity Tolerance | ±5% |
Withstand voltage | Vtet:1.6UN 5S (at20±5℃) |
Insulation Resistance |
C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min) C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min) |
Specification download: CBB20.pdf
